TP2 (C12200) Red Copper Seamless Pipe 127*4

TP2 (C12200) Red Copper Seamless Pipe 127*4*3860MM, Aluminium Brass Tube for Cooling and Heating

Additional information

Brand

DALING Special Steel (DLSS)

Certificate

ABS, DNV.GL, LR, BV, NK, PED, AD2000, ISO, CCS, CRN, API

MOQ

1PC

Delivery

20 Days

Testing

HT, ET

Product Details:

DALING SPECIAL STEEL, manufacturing and exporting Piping materials for more than 30 years, including Austenitic Stainless Steel, Super Duplex Steel, Nickel Alloy Steel (Hastelloy/Monel/Inconel/Incoloy), Copper and Copper Alloy Steel. DALING has the most advanced producing and testing equipments, our factory have been approved by: ABS, DNV.GL, BV, LR, NK, PED, AD2000, CCS, TS, ISO9001, ISO 14001, ISO18001, API, CRN No etc

So far, more than 3200 companies from 56 countries trust us, such as Italy, UK, Germany, USA, Canada, Chile, Colombia, Saudi Arabia, Russia, Korea, Singapore, Australia, New Zealand, Poland, France etc, the count is increasing.

DALING is not just producer, we are more like problem solvers and focus on creating value for customers.



TP2 Copper Pipe

Alloy No.: C12200, C1220, TP2.
Temper: Soft drawn, light soft drawn, hard, half hard.
Standard: ASTM B280, EN 12735, JIS H3300, GB/T 1527, AS/NZS 1571
Remarks: The same outside diameter with different wall thickness also available.



Technical Details of TP2/C12200 Pipe and Tube:

Alloy No. Chemical Composition Temper Mechanical Properties
Cu% P% Tensile Strength Elongation Grain Size
C12200 99.9 0.015-0.040 O60 205 Mpa ≥40% /
C12200 99.9 0.015-0.040 O50 245 Mpa ≥40% /



More about:

Standard Alloy No. Temper Chemical Composition Cu%
JIS H3300 C1220 H 1/2H OL O Minimum 99.90
BS2871 C106 H 1/2H / O
EN12735-2 CU-DHP Y0 80 / Y0 40 Y0 35
EN12735-1 or CW024A R360 R290 R250 / R220
EN1057 R360 R290 R250 / R220
EN12449 CU-DHP R360 R290 R250 / R220/R200
or CW024A H110 H095 H070 / H040
DIN SF-Cu F36 F25 F22 O
ASTM B68 C12200 / / O 50 O 60
B88 H58
B75 H80 & H58 H55 O 50 O 60
B280 H58 / O 60
B743-92a H58 / O 50 O 60



Applications:

  • Onshore and Off-Shore Applications
  • Air conditioner / Refrigeration
  • Construction water
  • Gas Field
  • Sea water cooling
